A2Z MOD-B1 Mobile & Portable PTZ Surveillance Cameras

A2Z MOD-B1 series Mobile / Portable PTZ Camera System delivers the perfect balance in high performing video, swift Pan-Tilt-Zoom operation, enhanced features plus diverse optional functions all with a superior price and compact size. The MOD-B1 PTZ series despite its smaller form-factor boasts rich capabilities with numerous potential configurations similar to other MOD series Pan/Tilt/Zoom Surveillance Cameras. Those core attributes allow them to provide professional results on par with other more common PTZ camera types from leading manufacturers, yet in a purpose-built design that is inherently better for tactical, vehicle or portable video applications of many kinds. A2Z MOD series PTZ cameras for instance can offer versions built to operate on major industry standards such as SDI for broadcast, CCTV and HD CCTV for analog or HD analog security camera systems and of course the most common versions of IP network based, supporting both professional IP Surveillance and a wide range of other IP-video system needs. With support for HD (i.e. 2MP / 1080p) up to Ultra HD (i.e. 8MP / 4K) resolutions, high optical zoom ranges, robust and weatherproof casing and other unique qualities benefitting remote deployments, the A2Z MOD-B1 series provides an exceptional choice even for projects which might otherwise be limited or impossible due to strict budgets.

A2Z MOD-B1 Main Features:

• Optional Visible w/IR Night Vision or Visible + Thermal IR Dual Camera Payload versions
• Superb 2MP / 1080p HD, 4MP / 2K QHD, 5MP / 3K SHD or 8MP / 4K Ultra HD Visible Video Module Options
• Up to VGA Resolution w/19mm (or similar fixed lens) Thermal IR (only Dual Payload w/Thermal versions)
• Powerful Visible Optical Zoom Lenses like 30x or 25x (Plus others)
• Excellent Low Light Performance - Color at Night Options
• High-Powered IR Night Vision with Effective Ranges up to 260ft!
• Video Digital Image Stabilization (DIS) helps reduce vibrations for stable imaging
• Advanced Image Processing with perks like WDR, Defog, 2D+3D Noise Reduction, etc.
• 360° Continuous Pan & -30° ~ 90° Tilt Range
• Multiple Format Versions: Options of SDI or CCTV / HD CCTV or IP Network types
• External Microphone Input Standard Option on IP models & some others
• True "Wire-Free" Wireless & Battery Versions Optional:
  - Adaptable Wireless Communications: 5G & 4G LTE cellular options w/WiFi & GPS support
  - Built-in Lithium Battery Pack for Stand-Alone operations (6+ hours depending on use/config)
  - Built-in LCD Text Display for status of Wireless Connections, Battery Capacity, SD card etc.
  - External IP67 Push-Button Power On/Off
• IP models by default support full function Web Browser Interface (live, search, playback, export) + Edge Storage up to 512GB
• Special Request (may include MoQ) IP Versions w/Web Interface, Mobile Apps & PC Software included optional
• IP Network versions w/Built-in Intelligent Video Analytics + A.I. powered video content analysis options
• IP Network versions grant diverse 3rd party system, software and mobile app integration with protocols like ONVIF, RTSP, etc.
• Excellent Weatherproof IP67 Rating - Rugged Wide Temp, Shockproof & Vibration Resistant
• Wide Range DC power input w/Added Power Protections
• Mobile Vehicle and Tactical Ready w/Quick Magnet Mount Base Option
• Optional Carry Case and Tripod Kits to other custom options possible.
• Optional Extra Vibration Damper / Shock Absorber Mount Accessory
• Optional Black or White Finish Models Standard Option
• NDAA Compliant Builds
• NOTICE: Actual Appearance May Vary based on Optional Configurations

A2Z MOD-B1 Portable & Vehicle PTZ Cameras deliver satisfying video in the latest HD to UHD standards with advanced image processing from WDR to DNR plus more for excellent clarity. Furthermore, while typical units include high-powered IR Night Vision, other builds such as the "SE" or "special edition" design can feature a dual camera module payload including Thermal Imaging for uniquely powerful dual sensor surveillance within that same incredible small rugged casing. Even more, the MOD-B1 series PTZ can accommodate different configurations with versions built to integrate with specific communication standards such as formats of SDI (i.e. 4G-SDI, etc.), different formats of analog CCTV or HD CCTV (i.e. CVBS, AHD, TVI, CVI) or finally network based video versions with universal IP protocols such as ONVIF, RTSP or RTMP and more. IP based versions offer cutting edge compression methods like H.264 and H.265 to a variety of other built-in abilities ranging from intelligent video analytics to on-board recording via SD card slot storage support.

The MOD-B1 Vehicle Portable PTZ Cameras include a specialized design not only boasting weatherproof ratings of IP66 and IP67, but additionally delivering important perks like shockproof, vibration resistant qualities to built-in magnetic base option allowing easy mounting plus rapid deployment in various tactical scenarios. IP Network based versions go even further, with optional models supporting Wireless communications like 4G LTE and WiFi as well as integrated lithium battery pack enabling truly stand-alone operation for many hours. Optional fixed mounts, extra vibration and shock absorber mounts to complete carry case with light weight tripod kits are also all available. Remote video surveillance, security monitoring, live-streaming, inspection, hunting and other task can all be achieved on the go with greater portable ease than ever before.
