A2Z MOD-T6 Vehicle & Tactical Dual Payload PTZ Surveillance Cameras

A2Z MOD-T6 Dual Payload, Portable, Tactical & Vehicle ready PTZ Camera series is a new, innovative line of Pan-Tilt-Zoom surveillance cameras uniquely produced and customized to meet a diverse range of professional video demands. The A2Z MOD-T6 "Modular Optical Device" or "Mobile Optical Device" "T6" series is a sleek mid-sized spherical PTZ Camera casing which includes not just a robust outdoor construction, but added vibration & shock-resistance plus more for rugged requirements. Its standard functions, specialized options and unique perks are especially suited for remote tactical and mobile system applications. Including numerous common conveniences the MOD-T6 also harnesses a variety of unique attributes not commonly found among standard security cameras. These units' chassis support a dual module payload including primarily optical and/or illumination device combinations which result in distinct versions. There are the Dual Spectrum kind with Visible and Thermal Imaging or alternatively enhanced Visible builds with high-power IR Night Vision or White Light Illumination types. Other major choices include options of signal format output like SDI, CCTV or HD CCTV as well as of course IP network connectivity ensuring adaptability to all sorts of professional video systems. Boasting numerous relevant control methods to high performing video and zoom capabilities the A2Z MOD-T6 PTZ Camera Systems are built to deliver top tier results be it fixed sites or especially mobile and remote surveillance needs.

A2Z MOD-T6 Main Features:

• Optional Visible Only + Auxiliary Illumination or Visible + Thermal IR Dual Camera Payload versions
• Superb 2MP HD, 4MP QHD or 4K Ultra HD Visible Video Module Options
• Up to VGA Resolution w/19mm (or similar fixed lens) Thermal IR (only Dual Payload w/Thermal versions)
• Powerful Visible Optical Zoom Lenses like 30x or 25x (Plus others)
• Excellent Low Light Performance - Color at Night Options
• High-Powered IR Night Vision versions with Effective Ranges up to 2600ft!
• High-Powered White Light Illumination versions Effective Ranges up to 985ft!
• Video Digital Image Stabilization (DIS) helps reduce vibrations for stable imaging
• Advanced Image Processing with perks like WDR, Defog, 2D+3D Noise Reduction, etc.
• 360° Continuous Pan & -30° ~ 90° Tilt Range
• Multiple Format Versions: Options of SDI or CCTV / HD CCTV or IP Network types
• External Microphone Input Standard Option on IP models & some others
• Optional True "Wire-Free" Wireless & Battery Powered Versions:
  - Adaptable Wireless Communications: 5G & 4G LTE cellular options w/WiFi & GPS support
  - Built-in Lithium Battery Pack for Stand-Alone operations (6+ hours depending on use/config)
  - Built-in LCD Text Display for status of Wireless Connections, Battery Capacity, SD card etc.
  - External IP67 Push-Button Power On/Off
• IP models by default support full function Web Browser Interface (live, search, playback, export) + Edge Storage up to 512GB
• Special Request (may include MoQ) IP Versions w/Web Interface, Mobile Apps & PC Software included optional
• IP Network versions w/Built-in Intelligent Video Analytics + A.I. powered video content analysis options
• IP Network versions grant diverse 3rd party system, software and mobile app integration with protocols like ONVIF, RTSP, etc.
• Excellent Weatherproof IP67 Rating - Rugged Wide Temp, Shockproof & Vibration Resistant
• Wide Range DC power input w/Added Power Protections
• Mobile Vehicle and Tactical Ready w/Quick Magnet Mount Base Option
• Optional Carry Case and Tripod Kits to other custom options possible.
• Optional Extra Vibration Damper / Shock Absorber Mount Accessory
• NDAA Compliant Builds
• NOTICE: Actual Appearance May Vary based on Optional Configurations

A2Z MOD-T6 Pan-Tilt-Zoom Dual Payload Surveillance Cameras deliver cutting edge HD to ultra-HD video resolutions with options for 1080p (2MP), 2K (4MP), 3K (5MP) or 4K (8MP) and optical zoom ratios like 30x, 33x, or 25x for its primary visible module. Superior image quality with enhanced image processing technologies such as DNR (digital noise reduction) or WDR (Wide Dynamic Range) to other advantages like Defog or DIS (Digital Image Stabilization) are all available. The A2Z MOD-T6 PTZs consistently adopt the latest generations of image sensors, optical zoom lens packages and other camera advancements to generate highly effective video on par with the latest peaks in industry standards. Operators can expect rich image settings accessible via methods like OSD (on-screen display) for coaxial based types or alternatively web browser interface for network (IP) based units. These flexible format types are further accompanied by complementing universal system abilities like Coaxial Control, RS-485 telemetry control or ONVIF protocol for easy universal network integration. All of this and more position the MOD-T6 for endless possible uses and wide adaptability with all sorts of 3rd party video solutions.

Typical builds of the MOD-T6 Vehicle / Portable PTZ Security Cameras then include a second alternative module payload choice with one such distinct selection being Thermal Imaging for a "Dual Sensor" or Dual Spectrum awareness function allowing operators to master all sorts of challenging scenes. On Thermal IR builds choices for up to 4CIF or D1 (i.e. approx. 640 x 480 pixels) and several fixed lens options benefit applications ranging from emergency, fire rescue or law enforcement missions to site security or infrastructure inspection task and beyond. Instead, the 2nd module payload selection can also be geared to greatly empower the visible module with high-powered, long range White LIGHT or Infrared Light, including Semi-Covert as well as Covert IR Night Vision is all available. Choices including LED and Laser based illumination variants are accessible, granting impressive results such as vivid color imaging or absolute night vision in zero lux environments at ranges up to hundreds of meters away. These fundamental characteristics along with yet mentioned pioneering functions assure the A2Z MOD-T6 PTZ platform can be configured in a manner that best suites an operators individual uses cases with ease for optimal system results.

Additionally, there are multiple more included plus potential add-on features that clearly display the A2Z MOD-T6 PTZ Cameras uniqueness. From granular points like AHD format with coaxial control support to work with modern HD CCTV video recorders or vehicle monitors to SDI coaxial signal transmission for Pro broadcast equipment, the MOD-T6 PTZs are ready to accommodate. Mean-while, the most popular type like the network IP based units similarly offer the latest relevant achievements and plenty more. For instance, network units include video compressions such as H.264 or H.265 while also covering common IT protocols like RTSP or RTMP, options for audio input to automated functions and more enable diverse integration possibilities. On-board detections or intelligent video analysis to the introduction of optional A.I. powered analytics the IP based MOD-T6 PTZ cameras standout with many specialized functions. Some of those most notable features or functions would be versions for totally stand-alone, truly wire-free operation. Such versions employ optional built-in hardware like Wireless transmission via 4G, 5G and WiFi communications plus on-board power with a built-in lithium battery pack to unveil a new age of tactical remote video.

Despite the device's efficient size and rugged casing with weatherproof ratings up to IP66 and IP67 standards, its Pan-Tilt-Zoom operation provides accurate, speedy movement with a high-grade Pan/Tilt mechanism. From continuous 360° Pan and an extended Tilt range the device offers full support for Pro-grade Pan-Tilt-Zoom actions like home position, park mode, preset positions to automated patterns or tours. However, MOD-T6 PTZs are by default unlike many common PTZs in that they provide the upright orientation install making it perfect for installations such as on a tripod or vehicle rooftop, yet optionally can also be installed in a hanging method such as from a ceiling or overhang with a smaller footprint than most comparably performing cameras for its size. The A2Z MOD-T6 PTZ cameras are built to facilitate professional video demands and therefore control communication standards like RS-485 Pelco D/P or ONVIF promise seamless integration with any Pro 3rd party joystick control equipment.

Last Updated April 7, 2025
