A2Z QPTZ9X Quick PTZ Xtreme Vehicle Portable 5G WiFi Battery IR IP Camera

A2Z QPTZ9X Quick PTZ Xtreme series introduces numerous new features to the QPTZ9 line, leveling up once again the already industry leading portable, vehicle and tactical pan-tilt-zoom camera solution. The QPTZ9X features a new rugged exterior case design which serves to provide new key functions distinct to the series. Those features include significant perks like a removable, swappable battery pack which along with extra batteries can indefinitely extend continuous in-field use. Another significant new feature is the unit's built-in speaker plus advanced dual microphone enabling two-way communication or simply comprehensive situational awareness with fluid video plus audio surveillance combined. Furthermore, the new A2Z QPTZ9X Quick PTZ IP Camera provides support for the latest 5G cellular connectivity while still supporting 4G LTE for wide area coverage in most regions. The QPTZ9X series unlike the QPTZ9 series is produced solely as an all-in-one truly wire-free network surveillance solution featuring on-board wireless communications, quick-swap lithium battery power packs and of course perks like intelligent detections, edge-storage and more for actual, totally stand-alone operation. High performing video including Pro Pan-Tilt-Zoom operation are melded into the perfect tool for a wide range of projects, missions and objectives. Ranging from Law Enforcement to Commercial or industrial inspection to simply live broadcast or remote monitoring, the device enables endless possibilities with ease like never before.

The A2Z QPTZ9X 5G IR PTZ IP Camera offers however several configuration options, including visible camera resolution options of full HD (2MP or 1080p), QHD (4MP or 2K) or UHD (8MP / 4K) with optical zoom lenses like 33x, 26x or 25x for high performing video rivaling any modern, pro video security camera. The unit is additionally offered in a dual payload version which pairs visible and thermal IR camera modules in a single unit for powerful dual spectrum video capabilities in a pre-made portable, rapid or tactical design once unheard of. These high-grade camera modules include super low light or starlight image sensors (visible modules) for exceptional imaging performance with added enhancements ranging from Image Stabilization to WDR, Defog or 3D / 2D Noise Reduction ensuring optimal image performance. Likewise, cutting edge compression methods such as H.265 and H.264 for video to G.7xx and high quality AAC audio codecs for surely professional results. Even more, numerous modern IT network protocols including ONVIF to RTSP standards are all available to accommodate seamless integration with third party systems and software. With powerful IR Night Vision effective up to 165ft included by default or optional IR Night Vision and Thermal IR configurations the device also guarantees effective surveillance in zero light environments.

Totally wire-free the A2Z QPTZ9X Quick PTZ Camera includes flexible wireless connection with cellular 5G, 4G, WiFi and even GPS transmission all supported, its integrated antennas are all cleanly concealed internally for convenient management. Additionally, its new removable battery pack with external battery charging dock plus optional extra batteries enable truly flexible operation similar to that of modern, cordless power tools. Supporting up to 10 hours operation per fully charged lithium battery pack (in low power mode with IR off) users can sustain long-term deployments with a minimal downtime of a couple minutes between battery swaps. Alternatively, the unit does include a weatherproof to breakout quick connect cable allowing continuous hardwired operation. An integrated Text LCD also provides quick reference for useful info like battery capacity as well as wireless communication status.

A2Z QPTZ9X 5G IR PTZ IP Cameras are built in a rugged, all metal casing including standards up to IP67 weatherproof rating including specifically shock-proof and like characteristics for superior performance and reliability in hash, mobile or remote deployments. The devices feature an integrated magnetic base capable of instant, temporary mounting to magnetic surfaces such as on vehicle exterior body or tactical tripods, only further solidifying its truly flexible abilities. Granular benefits from a built-in carry handle to mini eye-bolt safety cable ring are standard features while optional kits including carry cases and tripods are also all available. With a wide operating temperature range the device is also ready to take on exceptionally cold or hot severe weather.

A2Z QPTZ9X Quick PTZ Main Features:

• Optional Visible Only or Visible & Thermal IR Dual Camera Payload versions
• 2MP HD, 4MP QHD or 4K Ultra HD Visible Video Options
• Up to VGA Resolution w/19mm Fixed Thermal IR (only Dual Payload version)
• Powerful Optical Zoom Lenses like 33x or 26x / 25x (visible)
• Super Low Light Performance, Low Light Color (0.001 Lux on 2MP)
• High-Powered IR Night Vision Effective up to 50 meters
• Electronic Image Stabilization (EIS)
• Enhanced Imaging with WDR, Defog, 2D+3D Noise Reduction, etc.
• High-Efficiency, High Quality Video/Audio Compressions H.265, H.264, AAC, etc.
• Built-in Speaker & Built-in Advanced Dual Microphone
• Adaptable Wireless Communications: 5G & 4G LTE cellular, WiFi & GPS support
• Truly Wire-free operation with removable lithium battery pack
• Battery Pack charging dock included - Extra Batteries optional
• Built-in LCD Text Display for status of Wireless Connections, Battery Capacity, etc.
• Stand-alone operation with full function Web Browser Interface + Edge Storage
• Built-in Intelligent Video Analytics + A.I. powered video content analysis options
• Diverse 3rd party system, software and mobile app integration with protocols like ONVIF, RTSP, etc.
• Weatherproof to IP66 & IP67* (*cable quick connect), Wide Temp, Shockproof & Vibration Resistant
• Wide Range DC power input for hardwire connection - AC to DC battery pack charging dock
• Mobile Vehicle and Tactical Ready w/Quick Magnet Mount Base
• Optional Carry Case and Tripod Kits to other custom options possible.
• NDAA Compliant Build

A2Z QPTZ9X-2133 2MP 33x 5G Quick PTZ Sample Specifications:

Camera:
Imager Sensor: 1/2.8-inch CMOS
Maximum Image Size: 1920×1080 (1080p / 2 Megapixel)
Min. Illumination
Color: 0.001 Lux @ (F1.5, AGC ON);
B&W: 0.0005 Lux @ (F1.5, AGC ON)
Focus Length: 5.5mm～180mm
Aperture: F1.5～F4.0
Electric Shutter: 1/25 s~1/100000/s support slow shutter
Optical Zoom: 33× zoom
Zoom Speed: About 3.5s
Digital Zoom: 16× digital zoom
FOV: Horizontal FOV: 60.5°～2.3°（wide-telephoto）
Close Range: 100mm～1000mm（wide-telephoto）
Focus Mode: Auto/Semi-auto/Manual
Day & Night: Auto ICR Filter Shift
Gain Control: Auto/Manual
3D DNR: Support
2D DNR: Support
SNR: ≥55dB
White Balance: Auto/Manual/Tracking/Outdoor/Indoor/Auto sodium lamp/sodium lamp
Image Stabilization: Support
Defog: Support
BLC: Support

WIRELESS COMMUNICATIONS:

WIFI:
Protocol Standard: IEEE 802.11a/IEEE 802.11an/IEEE 802.11ac
Wireless Communication Speed: up to 866Mbps
Channel Selection: 36～165 Band
Band Width: 20/40/80MHz options
WIFI Security: WPA-PSK/WPA2-PSK、WPA-PSK、WPA2-PSK。
5G Wireless Transmission:
Protocol Standard: 3GPP Release 15
Network Mode: NSA/SA
Working Frequency Band / Frequency:
5G NR
DL 4×4 MIMO (n1/41/77/78/79)
DL 2×2 MIMO (n20/28)
UL 2×2 MIMO (n41/77/78/79)
DL 256 QAM，UL 256 QAM
4G LTE:
DL 2×2 MIMO
(B1/2/3/4/5/7/8/20/26/28/34/38/39/40/41)
DL 256 QAM，UL 64 QAM
WCDMA: B1/8
SIM Card: Support dual NANO SIM Card
Positioning system (optional): Built in GPS Navigation Satellite System
Audio - Talkback / Two-Way Audio
Microphone: Built-in Microphone, dual Microphone noise technology
Speaker: Built-in 2W speaker
Wired Audio: Input; output options when hardwired

Lithium Battery
Battery Type: Dismountable Polymer lithium battery with high capacity
Capacity: 14.4V 6700mAH(96.48wh)
Duration: 10 hours (IR closed, low power mode)

Video & Functions
Main Stream:
50Hz: 25fps (1920 × 1080, 1280 × 960, 1280 × 720);
60Hz: 30fps (1920 × 1080, 1280 × 960, 1280 × 720)
Second Stream:
60/50hz 30/25fps @ D1/VGA resolution max
Third Stream
50Hz: 25fps (1920 ×1080);
60Hz: 30fps (1920 ×1080)
Video Compression: H.265 (Main Profile) / H.264 (Baseline Profile / Main Profile / High Profile) / MJPEG
Audio Compression: G.711a/G.711u/G.722.1/G.726/MP2L2/AAC/PCM
Network Protocols: IPv4/IPv6, HTTP, HTTPS,802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE
ROI: Support
Regional Exposure/Focus: Support
Time Demonstration: Support
API: ONVIF (PROFILE S, PROFILE G), SDK
User/Host: Up to 6 users
Security: Password Protection, complicated password, host authentication (MAC address); HTTPS encryption; IEEE 802.1x (White list)

On-board Storage Options
Memory Card: Built-in memory card slot, support Micro SD/SDHC /SDXC card; up to 256GB edge-storage
Network Storage: NAS (NFS, SMB/CIFS)

PTZ
Pan Range: 360°
Pan Speed: 0.05～80°/s
Tilt Range: -25～90°
Tilt Speed: 0.05～60°/s
Presets: 255
Patrol Scan: 6 patrols, up to 18 presets for each patrol
Pattern Scan: 4
Power off Memory: Supported

IR
IR Distance: 50 meters
Auto-Adjust: Yes, proportional to optical zoom
Wavelength: Default 850nm Semi-covert

Interface
Card Interface: NANO SIM Slot*2， Dual SIM Cards, single standby
SD Card Interface: Micro SD Slot*1，up to 256GB
Audio Interface: 1x Input 1x Output (hardwire connection)
Alarm Interface: 1x Input,1x Output (hardwire connection)
Network Interface: 1x RJ45 10M/100M self-adaptive Ethernet
Power Interface: DC5.5*2.1F

General
Power: Wide Range DC 9～24V (hardwire connection)
Power Consumption: MAX 60W
Work Temperature: -20～60°C
Camera Weight: 4.5Kg
