Bosch NDC-274-P 1080p HD MicroDome IP Dome Security Camera

Bosch NDC-274-P 1080p HD MicroDome IP Camera is a powerful indoor High Definition network security cameras with ultra-low profile design. The Bosch MicroDome Series is an indoor mini dome HD 1080P IP Camera that delivers stunning real-time high definition imaging and includes multi-streaming with MJPEG and advanced H.264 compression technology. The Camera features Real-time 30fps IP Surveillance and is outfitted with a wide angle 4.37mm lens for general purpose coverage in a variety of ip camera system applications. The Bosch MicroDome NDC-274-P IP Dome Camera also includes a built-in microphone for audio surveillance.
The Bosch NDC-274-P 1080p HD MicroDome IP Dome Camera also provides an all in one HD IP Security Camera System. The unit features built-in Detection methods and with a high capacity MicroSDHC Card Slot offers up to 2TB (2048GB) of local recording storage. Other advantages include the multiple power input options including 12VDC, 24VDC and PoE (Power Over Ethernet) standard IEEE 802.af. The Bosch MicroDome HD IP Dome Security Cameras are also ONVIF complaint making them a perfect choice third party camera systems.

Bosch NDC-274-P Main Features:

• 1080P HD (High Definition) Video Surveillance
• Real-time 30fps Video Multi-streaming in H.264 or MJPEG
• 4.37mm Wide Angle Fixed Lens.
• Ultra-low profile, indoor compact mini dome camera
• Internal Camera Pan and Tilt Adjustments
• Two Way Audio, Alarm Input, Relay output and (Service Only) Monitor Output
• ONVIF Support for integration with third party IP Systems.
• Flexible Power Input with 12VDC, 24VDC and PoE Support

Bosch NDC-274-P Technical specifications:

Power
Input voltage
+12 VDC, +24 VDC or Power-over-Ethernet (48 VDC nominal)
Power consumption
3.84 W (max)
Video
Sensor type
1/2.7-inch CMOS
Sensor pixels
1920 x 1080
Sensitivity
0.3 lx
Video resolution
1080p, 720p, 480p, 240p
Video compression
H.264 MP (Main Profile); M-JPEG
Max. frame rate
30 fps (M-JPEG frame rate can vary depending on system loading)
Lens
Lens type
4.37 mm fixed, F2.0
Lens mount
Board mounted
View angle
67.4° (H), 40.8° (V)
Connection
Analog video out
2.5 mm jack for installation only (NTSC)
Audio
Audio input
Built-in microphone
Audio compression
G.711, L16 (live and recording)
Local Storage
Memory card slot
Supports up to 32 GB microSDHC / 2 TB microSDXC card
(An SD card of Class 6 or higher is recommended for HD recording)
Recording
Continuous recording, ring recording. alarm/events/schedule recording
Software Control
Unit configuration
Via web browser or PC surveillance software
Network
Protocols
IPv4, IPv6, UDP, TCP, HTTP, HTTPS, RTP, IGMP V2/V3, ICMP, RTSP, FTP, Telnet, ARP, DHCP, SNTP, SNMP (V1, MIB-II), 802.1x, SMTP, iSCSI, UPnP(SSDP)
Encryption
TLS 1.0, SSL
Ethernet
10/100 Base-T, auto-sensing, half/full duplex
Ethernet connector
RJ45
PoE
IEEE 802.3af compliant
Mechanical
Dimensions
Diameter: 105 mm (4.13 in)
Height: 56 mm (2.2 in)
Weight -
255 g (8.99 oz.) approx.
Environmental
Operating temperature
-20 ºC to +50 ºC (-4 ºF to +122 ºF)
Storage temperature
-20 ºC to +70 ºC (-4 ºF to +158 ºF)
Humidity
10% to 80% relative humidity (non-condensing)
Standards
Standards
EN 60950-1: 2006, Reference IEC 60950-1:2005
UL 60950-1: 1st edition dated October 31, 2007
CAN/CSA-C22.2 NO. 60950-1-03
EN 50130-4:1995 + A1:1998 + A2:2003
FCC Part15 Subpart B, Class B
EMC directive 2004/108/EC
EN 55022 class B
EN 61000-3-2 :2006
EN 61000-3-3 : 1995+A1 :2001+A2 :2005
EN 55024
AS/NZS CISPR 22 (equal to CISPR 22)
ICES-003 Class B
EN 50121-4:2006
Product certifications
CE, FCC, UL, cUL, C-tick, CB, VCCI
Certifications and approvals
Region
Certification
Europe
CE
USA
UL
FCC
Canada
CSA
Ordering information
NDC-274-P 1080p Indoor MicroDome Cam-
era
NDC-274-P
IP200 MicroDome camera adapter bracket
NDA-MBR-DOME
IP200/MicroDome cameras wall
mount

Order Info:

NDC-274-P 1080p Indoor MicroDome Camera
NDC-274-P IP MicroDome 1080p
Commercial Type No: NDC-274-P
