Geovision GV-3008A 8ch DVR Capture Card H.264

Geovision GV-3008A 8ch DVR capture cards are cutting-edge H.264 Hardware Compression DVR capture cards for flawless real-time full resolution CCTV video surveillance. The Geovision GV3008A DVR Cards has on board H.264 compression for superb video quality with optimized storage and bandwidth reduction. The DVR Card is a unit that offers 240fps Real-time viewing and recording on all 8 channels in Full D1 (4CIF) High resolution. The capture card additionally provides 8 channel audio inputs with AAC compression format for superior Audio quality. The Geovision GV-3008A DVR cards are built to provide the highest performance and quality video in an 8ch DVR Capture cards. The GV-3008A can be stacked 2 cards per PC for a total 480fps and 16 channels of Real-time Full D1 Recording and Viewing. The additional GV-3008A can be installed at a later time or you can order two at once for a discount as product GV-3016A.
Geovision GV-3008A benefits from the vast array of Geovision Software including easy to operate local and remote viewing for complete DVR functions such as live viewing, search, playback and export. The Geovision Main Software application is feature rich yet provides a simple to navigate GUI loaded with the ability to support up to 32ch of video per PC DVR. The Geovision GV-3008A DVR Cards also allow a wide selection of advanced monitoring choices such as CMS software, Web browser, Remote client and even Smart Phone or Tablet viewing on Android, Iphone or Ipad. The Geovision GV-3008A Series DVR capture Cards further support integration with a variety of accessories such as Audio, I/O or POS systems for centralized and intelligent security camera system designs. Geovision GV3008A DVR Card Systems also are fully compatible with other Geovision Surveillance Systems and offers single system operation for Hybrid CCTV, HD-SDI CCTV and IP Network Security Camera Systems. Among the Gevision line of DVR Capture Cards the GV-3008A as a top model card for High Grade Video Monitoring and Surveillance System requirements.

Geovision GV-3008A Main Features:

• 8ch Real-time 240fps Full D1 (4CIF) Live Viewing and Recording
• Built-in H.264 Hardware Compression for Enhanced Performance
• Features High Quality AAC Audio Compression with 8 channels
• Stacking of up to 2x GV-3008A DVR cards allows 16ch Real-time 480FPS
• Supports All Geovision Software including CMS, Client, Smart Phones: Android, Ipad, Iphone
• Supports Hybrid System designs for CCTV, HD SDI and IP Camera system integration

Geovision GV3008A Specifications:

• Interface PCI-E (x1) PCI-E (x1) x 2
• Input Type    D-Type D-Type
• Video Input 8 Channels
• Audio Input 8 Channels
• Recording Rate (D1): NTSC 240fps PAL 200fps
• Display Rate: NTSC 240fps PAL 200fps
• Video Resolution NTSC: H/W 704 x 480 S/W 352 x 240
• Video Resolution PAL: H/W 704 x 576 S/W 352 x 288
• Video Compression S/W Geo MPEG4, Geo H264 Format H/W H.264
• Audio Compression Format AAC (16 kHz / 16 bit)
• Bit Rate Range 2.5M ~ 10M
• GV-Net I/O Card Support: Yes
• GV-Multi Quad Card Support: Yes
• GV-Loop Through Card Support: Yes
• Hardware Watchdog: Yes
• Dimensions (W x H): 180x112 (mm) / 7.09x4.41 (in)
• Installation Guide GV-3008A and Geovision Software

Note:
1. GV-3008 does not support the TV-Out function.
2. GV-3008 is currently not compatible with VIA series, ATI series, Intel Sandy Bridge series and NVIDIA series chipset motherboards.GV-3008 February 9, 2012
Minimum System Requirements For One Card
32-bit Windows XP / Windows Vista / Windows 7 / Windows Server 2008 /
OS Supported
64-bit Windows 7 / Windows Server 2008 R2/
CPU    Core 2 Duo, 2.33 GHz
RAM    2 x 1 GB Dual Channels
HDD    250 GB
Graphic Card AGP or PCI-Express, 800 x 600 (1280 x 1024 recommended), 32-bit color
DirectX 9.0c
Power Supply 400 Watts

.
