Milesight MS-C2972-RFIPE 2MP AI 5x IR Vandal Dome IP Security Camera

Milesight MS-C2972-RFIPE 2MP AI Motorized Pro IR Vandal Dome Network Cameras are the full featured choice for sophisticated, yet simplified video security and surveillance system applications. Boasting super high frame video in full 1080p HD these units combine the best perks of modern video security including P-Iris motorized lens to true wide dynamic range and absolute IR night vision all combine for exceptional image quality. Complete scene awareness can also be appreciated thanks to a built-in microphone. Additional attributes such as weatherproof and vandalproof design ensure readiness for indoor or outdoor applications. The Milesight MS-C2972-RFIPE IR Vandal Dome IP camera is also ONVIF and NDAA complaint allowing easy integration with 3rd party security systems and safe use in sensitive projects respectively.



Milesight MS-C2972-RFIPE Main Features:

Milesight MS-C2972-RFIPE Specifications:



2MP NDAA AI Motorized Pro Dome Network Camera

Image Sensor: 1/2.8" Progressive Scan CMOS

Min. Illumination: Color: 0.005 Lux @F1.4, B/W: 0Lux with IR on

WDR 140dB (Super Wide Dynamic Range)

Shutter Time: 1/100000s~1s

Day/Night Mode Day/Night/Auto/Customize/Schedule

IR Night Vision 50m (3.0~10.5mm/2.7~13.5mm) or Up to 90m (7~22mm)

S/N: >55dB

Motorized Lens: 2.7~13.5mm (Default) 3.0~10.5mm or 7~22mm (Special Order) @F1.4, P-Iris

Field of View: HFOV 115°~H34°/DFOV 135° ~ DFOV 39° / VFOV 62° ~ VFOV  19° (2.7~13.5mm Special Order)

               HFOV 102°~H34°/DFOV 118° ~ DFOV 38° / VFOV 56°~VFOV 19° (3.0~10.5m Special Order)

Lens Mount: Φ14

Focus Control: Auto/Manual

Iris Control: P-Iris Auto/Manual

Video Max. Image Resolution: 1920x1080 2MP (1080o)

Primary Stream:

60Hz: 90fps@(1920x1080) (Optional for T Series), 60fps@ (1920x1080, 1280x960, 1280x720, 704x576)

50Hz: 90fps@(1920x1080) (Optional for T Series), 50fps@ (1920x1080, 1280x960, 1280x720, 704x576)

Secondary Stream:

60Hz: 90fps@(704x576) (Optional for T Series), 60fps@ (704x576, 640x480, 640x360, 352x288, 320x240)

50Hz: 90fps@(704x576) (Optional for T Series), 50fps@ (704x576, 640x480, 640x360, 352x288, 320x240)

Tertiary Stream:

60Hz: 30fps@ (1280x720, 704x576, 640x480, 640x360, 352x288, 320x240)

50Hz: 25fps@ (1280x720, 704x576, 640x480, 640x360, 352x288, 320x240)

Video Compression: H.265+/H.265(HEVC)/H.264+/H.264/MJPEG

Video Bit Rate: 16Kbps~16Mbps (CBR/VBR Adjustable)

Privacy Masking Up to 24 areas

ROI Up to 8 areas

Image Settings: Saturation/Brightness/Contrast/Sharpness

Interface Ethernet: 1*RJ45 10M/100M Ethernet Port

Audio I/O: Built-in Microphone and 1 Audio Output interface

Alarm I/O: 1/1 input/output for external Sensor/Relay

Network

Network Storage: NAS (Support NFS, SMB/CIFS), ANR

Network Protocols: IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL

Audio Compressions: G.711/AAC/G.722/G.726

Audio Sampling Rate: 8/16/32/44.1/48KHz

Audio Bit Rate: 16~256kbps

Two-way Audio: Support

Intelligent Analytics

Video Analysis: Intrusion Detection, Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Object Left, Object Removed

Face Detection & Face: Attribute Recognition, Detect and capture faces, get real-time snapshots; The attributes include Age, Gender, Glasses, Mask and Cap, Support Faces Privacy Mode, the detected faces in the face detection area will be mosaic automatically.

Object Counting & Report: Count the number of objects crossing the line, optionally human and vehicle,

Support regional people counting for up to 4 detection areas

System

Storage Support: microSD/SDHC/SDXC Card Local Storage, up to 1TB

Advanced Function: Heat Map, BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Deblur, Watermark

SIP/VoIP Support: Yes, Voice & Video-over-IP

Event Trigger: Motion Detection, Network Disconnection, Audio Alarm, External Input, etc.

Event Action: FTP Upload, SMTP Upload, SD Card Record, External Output, SIP Phone, HTTP Notification, etc.

System Compatibility: ONVIF Profile G & M & S & T, API

General Working Temperature: -40~60 C

Working Humidity: 0~90%(Non-condensing)

Power Supply: PoE(802.3af) or DC 12V±10%

Power Consumption: 6W MAX, 8W MAX (With IR on)

Weather Proof: Up to IP67-rated for Weather-resistant Performance

Housing Vandal-proof IK10-rated Metal Housing

Weight: 1100g

Dimensions: Φ143mm X 108.4mm

Warranty: 3 Years (5 Year option)
