Milesight MS-C9674-PA 12MP AI 360° Fisheye Panoramic IP Security Cameras

Milesight MS-C9674-PA 12MP AI 360° Fisheye IP Cameras are a top-of-the-line solution for total area coverage with high detail and many added benefits from a single mounting point. Equipped with a 12 Megapixel Image sensor these Fisheye cameras can provide numerous viewing needs including full 360° or dual Panoramic 180° while further including all sorts of viewing functions. With built-in DE warping the and benefits like plug-in free web browser support the devices can even offer full functionality without the need of additional parts and software, even though mobile apps and PC software is also provided. The device gives true day/night operation while including IR Night Vision and WDR for superb imaging results in all types of environments, again without the need of any added accessories. Flexible mounting is supported including both indoor or outdoor applications thanks to a robust weatherproof and vandalproof construction not to mention a unique, low profile integrated junction box for easy cabling. There are simply to many benefits to name them all, a built-in Microphone to external device support for both Sensor/Relay and Audio I/O is also on-board. ONVIF compliance to Micro SD card slot the Milesight MS-C9674-PA 12MP AI 360° Fisheye IP Security Cameras are well outfitted for nearly any project demands.

Milesight MS-C9674-PA Main Features:

• 1/1.7" 12 Megapixel Fisheye 360° Panoramic View
• Fisheye 3000 x 3000 at up to 30fps Real-time
• Panoramic Fisheye Fixed Lens 1.98mm
• Viewing Angles: Ceiling: 360° / Wall: 180° / Flat: 360°
• Panoramic 360° IR Night Vision 15m
• Color: 0.05 Lux @F2.8 / B/W: 0 Lux IR ON
• Super WDR 120dB
• A.I. (Artificial Intelligence) Vehicle/Human Detection
• 3-Axis Camera Orientation
• ONVIF for 3rd Party Security Systems
• Micro SD Card Support
• Built-in Microphone
• Two Way Audio: I/O (Input/Output) for external Mic/Speaker
• Alarm I/O (input/output) for external Sensor/Relay
• White / Black Housing
• Weatherproof up to IP67 rating
• Vandalproof High Impact IK10 rating
• Integrated Junction Box
• PoE OR 12VDC Power Support

Milesight MS-C9674-PA Specifications:

12MP NDAA AI 360° Fisheye Network Camera
Image Sensor 1/1.7" Progressive Scan CMOS
Min. Illumination: Color: 0.01 Lux @F1.2, Color: 0.05 Lux @F2.8, B/W: 0 Lux with IR on
WDR 120dB Super Wide Dynamic Range
Fisheye Fixed Lens: 1.98mm@F2.8
Lens Mount: M12
Field of Views: Ceiling Mount:360°; Wall Mount:180°; Flat Mount:360°
Shutter Time: 1/100000s~1s
Day/Night Modes: Day/Night/Auto/Customize/Schedule
IR Night Vision: 15m 360°
S/N: >55dB
Display Mount Modes: Ceiling Mount / Wall Mount / Flat Mount
Decoding Modes: On-board De-warping/Client-side De-warping
Display Modes: 11 display modes in total.
Client-side De-warping:
Ceiling Mount: 1O, 1P, 2P, 4R, 1O3R, 1P1R, 1P4R, 1P6R, 1O8R
Wall Mount: 1O, 1P, 4R, 1O3R, 1P1R, 1P4R
Table Mount: 1O, 1P, 2P, 4R, 1O3R, 1P1R, 1P4R, 1P6R, 1O8R
On-board De-warping:
Ceiling Mount: 1O, 1P, 2P, 4R, 1O3R, 1P3R, 1O1P3R
Wall Mount: 1O, 1P, 4R, 1O3R, 1P3R, 1O1P3R
Table Mount: 1O, 1P, 2P, 4R, 1O3R, 1P3R, 1O1P3R
Note:
1. Only Fisheye in Multi-Channel Mode supports 1O1P3R.
2. The above letters O, P and R are explained as follows: O = Fisheye View; P = 180° Fisheye View; 2P = 2x 180° Panoramic View; R = PTZ (digital)
Video Max. Input Resolution: 12 Megapixel / 4000x3000
Primary Stream:
Fisheye View:
60Hz: 30fps@ (3000x3000, 2560x2560, 1920x1920, 1280x1280)
50Hz: 25fps@ (3000x3000, 2560x2560, 1920x1920, 1280x1280)
Secondary Stream:
Fisheye View:
60Hz: 30fps@ (1280x960, 1024x1024, 736x736, 576x576)
50Hz: 25fps@ (1280x960, 1024x1024, 736x736, 576x576)
Video Compression: H.265+/H.265(HEVC)/H.264+/H.264
Video Bit Rate: 16Kbps~16Mbps (CBR/VBR Adjustable)
Privacy Masking: Up to 24 areas
ROI: Up to 8 areas
Image Settings: Saturation/Brightness/Contrast/Sharpness
Web Browser Support: IE/Firefox/Chrome/Safari Browser
Audio Compression G.711/AAC/G.722/G.726
Audio Sampling Rate 8/16/32/44.1/48KHz
Audio Bit Rate: 16~256kbps
Two-way Audio: Support
Interface Ethernet: 1*RJ45 10M/100M/1000M Ethernet Port
Audio I/O: Built-in Microphone and Audio Input/Output interface
Alarm I/O: 1/1 Input/Output for External Sensor/Relay
Network Storage NAS (Support NFS, SMB/CIFS), ANR
Network Protocols: IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, UPnP, Bonjour, SIP, SNMP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL
Intelligent Analytics / Video Analysis: Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Object Left, Object Removed
People Counting & Report: Count the number of people entering or exiting, up to 4 detection areas for regional people counting
On-board Storage Support: microSD/SDHC/SDXC Card Local Storage, up to 256G
Advanced Function: Auto Tracking, Heat Map, BLC, HLC, 2D DNR, 3D DNR, AWB, IP Address Filtering, AGC, Anti-flicker, Deblur, Watermark
SIP/VoIP Support: Yes, Voice & Video-over-IP
Event Trigger: Motion Detection, Network Disconnection, External Input, Audio Alarm, etc.
Event Action: FTP upload, SMTP upload, SD card record, External Output, SIP Phone, HTTP Notification, etc.
3rd Party Video Security System Compatibility: ONVIF Profile G & Q & S & T, API
General Working Temperature: -40° ~ 60° C
Working Humidity: 0~90%(Non-condensing)
Power Supply: PoE(802.3af)/DC 12V±10%
Power Consumption: 6W MAX, 11W MAX (With IR on)
Weather Proof Up to IP67-rated for Weather-resistant Performance
Housing Vandal-proof IK10-rated metal housing
Dimensions: Φ140mmX45.4mm
Weight: 700g
Warranty: 3 Years (5 Year option)
