Milesight TS5366-X12PE 5MP Road Traffic AI LPR 12x IR Bullet IP Security Camera

Milesight TS5366-X12PE 5MP Road Traffic AI LPR 12x IR Bullet IP Security Camera is a special version of the Pro Bullet Plus series incorporating an advanced suite of built-in Video Analytics focused on vehicle traffic applications. Boasting superior video clarity up to 5-megapixel super HD resolutions, the unit is well equipped for roadway monitoring thanks to excellent low light performance backed by high-powered IR Night Vision and a long rang optical zoom lens among other video enhancements. Across the board this Bullet IP Camera is outfitted to meet a vast array of project demands even before considering its unique video content analysis abilities. Advantages from high-capacity edge storage support to a well-developed web browser user interface with rich functionality, the device delivers satisfying capabilities in every regard. Cutting edge compression methods, flexible hardware and software integration to a robust, high impact resistant, wide temp and strict weatherproof construction, there is very little this innovative network surveillance camera doesn't provide.

Milesight TS5366-X12PE 5MP Road Traffic A.I. LPR 12x IR Bullet IP Cameras are exceptionally positioned for surveillance and monitoring of vehicle traffic along numerous types of public roads including but not limited to all types of streets and even highways, freeways, toll roads or expressways when placed strategically within their max speed capabilities. The units include an AI powered ANPR (Automatic Numeric Plate Recognition) or aka ALPR (Automatic License Plate Recognition) video analytic with high accuracy effectiveness. Additionally included are other granular vehicle attribute detections to purpose-built functions like traffic violation detections and traffic flow statistics allowing multiple potential deployment purposes. These and other advanced video content analysis functions are all achieved at the edge or in other words on-board the camera itself and this alone is a significant advantage to previous market solutions. With this capability the Milesight TS5366-X12PE A.I. LPR IP Camera enables numerous possible forms of deployment including stand-alone abilities to more comprehensive features when used in junction with Milesight NVRs, VMS or CMS Software products. Finally, third party system integration is widely supported with methods as simple as utilizing modern ONVIF formats to custom developed projects including access to SDK / API / CGI options for full accessibility of their powerful benefits.

Milesight TS5366-X12PE Main Features:

• 1/2.8" 5 MegaPixel (2592x1944) @ 30fps Real-time
• Zoom lens: 5.3~64mm, 12X Optical Zoom: HFOV 57° ~ HFOV 4°/ VFOV 44° ~ VFOV 1°
• High Power IR Night Vision up to 180m
• ANPR Day Range up to 150m - ANPR Night Range w/Illumination: up to 80m
• Color: 0.005 Lux @ F1.2, Color: 0.008 Lux @F1.6, B/W: 0 Lux with IR on
• Super Wide Dynamic Range (WDR 120dB)
• A.I. (Artificial Intelligence) Powered LPR Algorithm
• Long Range ANPR Function w/95% Accuracy
• High Speed ANPR up to Approx. 75mph - 2 Lane Coverage
• Numerous Vehicle Attributes: Color, Brand, Type, Direction, No-Plate, Plate Color
• Traffic Violation Detection
• Traffic Flow Statistics
• Evidence Camera Linkage
• High-Capacity Edge White/Black List
• 3-Axis Camera Orientation
• ONVIF, CGI/API/SDK and more for 3rd Party Systems
• Multi-Web Browser Support - Plug-in Free
• High-Capacity Micro SD Card Support
• Audio External I/O device support (i.e. mics/speakers)
• Alarm/Relay External I/O device support
• White Housing
• Weatherproof up to IP67 rating
• Vandalproof High Impact IK10
• Optional Heating Module (for -60°C)
• A62 Junction Box Included
• Surge Protection
• PoE OR 12VDC Power Support

Milesight TS5366-X12PE Specifications:

Camera
Name NDAA AI Road Traffic Pro Bullet Plus Camera
Image Sensor 1/2.8″ Progressive Scan CMOS
Min. Illumination Color: 0.008Lux@F1.6
B/W: 0Lux with IR on
WDR 120dB Super WDR
Shutter Time 1/100000s~1s
Day/Night Mode Day/Night/Auto/Customize/Schedule
IR Wave Length 850nm (Default); 740nm (Optional)
Illumination Distance Up to 180m
S/N >55dB

Lens
Lens 5.3~64mm, 12X Optical Zoom
Field of View H57°~H4°/D69°~D5°/V44°~V1°
Mount Φ14
Focus Control Auto/Manual
Aperture F1.6~F2.8
Iris Control Auto

Road Traffic Management
Max. Vehicle Speed 120km/h
Recognition Accuracy >95%
Coverage 2 lanes
Country Region Supported More than 80 countries and regions
ANPR Distance Up to 150m during the day; Up to 80m during the night with illumination
Attributes Identification Plate Color, Vehicle Type, Vehicle Color, Vehicle Brand,
No-plate Vehicle Capture, Vehicle Direction Detection
Smart Traffic Function Evidence Camera Linkage, Specific Lane Management
White/Black List Up to 20,000 records inside the camera
LPR Smart Search Support

Interface
Ethernet 1*RJ45 10M/100M Ethernet Port
Audio I/O 1/1
Alarm I/O 1/1 (Integrated Cable Version) 2/2 (Cable Out Version)

Video
Max. Image Resolution 2592x1944
Primary Stream 60Hz: 30fps@ (2592x1944, 2592x1520, 2048x1536, 1920x1080, 1280x960, 1280x720, 704x576)
50Hz: 25fps@ (2592x1944, 2592x1520, 2048x1536, 1920x1080, 1280x960, 1280x720, 704x576)
Secondary Stream 60Hz: 30fps@ (704x576, 640x480, 640x360, 352x288, 320x240)
50Hz: 25fps@ (704x576, 640x480, 640x360, 352x288, 320x240)
Tertiary Stream 60Hz: 30fps@ (1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240)
50Hz: 25fps@ (1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240)
Video Compression H.265+/H.265(HEVC)/H.264+/H.264/MJPEG
Video Bit Rate 16Kbps~16Mbps (CBR/VBR Adjustable)
Privacy Masking Up to 8 Areas (Mask Area and Mosaic Area are optional)
ROI Up to 8 areas
Image Setting Brightness/Contrast/Saturation/Sharpness

Network
Network Storage NAS (Support NFS, SMB/CIFS), ANR
Protocol IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL, TLS 1.2

Audio
Audio Compression G.711/AAC/G.722/G.726
Audio Sampling Rate 8/16/32/44.1/48KHz
Audio Bit Rate 16~256kbps
Two-way Audio Support

System
System Compatibility API, HTTP, TCP, ONVIF Profile G & M & S & T
Storage Support microSD/SDHC/SDXC Card Local Storage, up to 1TB
Advanced Function BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, IP Address Filtering, AGC,
Anti-flicker, Corridor Mode, Deblur, Watermark
SIP/VoIP Support Yes, Voice & Video-over-IP
Event Trigger Black/White List, Attributes Event, Motion Detection,
Network Disconnection, External Input, Audio Alarm, etc.
Event Action FTP Upload, SMTP Upload, SD Card Record, External Output, SIP Phone, HTTP Notification, etc.

General
Working Temperature -40°C~60°C
Working Humidity 5~90%(Non-condensing)
Power Supply PoE (802.3at) / DC 12V±10%
Power Consumption 8W MAX
13W MAX (With IR on)
Weather Proof Up to IP67-rated for Weather-resistant Performance
Housing Vandal-proof IK10-rated Metal Housing
Surge Protection 4KV
Weight 1623g
Dimensions 320mmX134mmX171mm
Warranty 3/5 Years
