Milesight TS5510-GH TrafficX High Speed Road A.I. LPR IR Strobe Dual IP Camera System

Milesight TS5510-GH TrafficX High Speed Road A.I. LPR IR Strobe Dual IP Camera System is a unique, pre-built solution for the most demanding traffic monitoring and surveillance requirements. The device boasts two 5-Megapixel 2/3" Image Sensors with the top tier function of a Global Shutter enabling this road traffic camera system to capture super sharp clarity of fast-moving objects (vehicles) unlike other even high-end, yet common security cameras. Additionally, each is outfitted with a motorized telephoto zoom lens and aa special perk of a built-in Infrared Strobe Light for the most professional technique of traffic surveillance capture. These factors enable this single unit to deliver both over-view evidence and close up lane capture such as for its LPR function, including up to 3 lane coverage at once. The Milesight TrafficX A.I. ALPR Dual IP Camera has many powerful on-board advantages as well as options to empower the latest in smart transportation management. Such options like aa built-in 4G cellular module to alternate IR wavelengths allow the Milesight TrafficX to accommodate the widest range of vehicle traffic applications. All of this and more is provided in a rugged, compact enclosure with high weatherproof ratings and extended operating temperatures for maximum adaptability.

Milesight TS5510-GH TrafficX A.I. LPR IR Strobe Dual Sensor IP Camera System is unquestionably well prepared on the hardware level, yet its software layers and Artificial Intelligence powered Video Analysis all combined is what sets this device apart from all others. Including a well-developed web browser interface supporting stand-alone uses, the system has all the key features to enable sophisticated, yet easy to implement next generation vehicle traffic monitoring with rich metadata. This is all built to serve not just stand-alone operations with intelligent Video Analytic processing at the edge, but further to support Milesight NVR, VMS or CMS software as much as it is for 3rd party systems or custom developed systems. From ALPR (automatic license plate recognition) or ANPR (Automatic Numeric Plate Recognition) as it is also often called, this innovative solution provides much more granular data such as vehicle types, vehicle brand, vehicle color, direction and more. Vehicle behavior detections with automated notifications to GPS locating are all among its potential uses while diverse IT protocol support allows countless possible deployment methods. From improving community security and safety to supporting special purpose requirements like enforcing regulations of Low Emission Zones, the next generation of smart traffic management begins with the Milesight TrafficX Cameras.

Milesight TS5510-GH Main Features:

• 2/3" Global Shutter 5-Megapixel Dual Sensors
• Dual-Camera for Overview and ANPR
• Motorized Autofocus 15-50mm Lenses - HFOV 41.4° to 10.3°
• Specialized IR Strobe 850nm up to 60m - (740nm optional)
• High-performance AI Chip and AI ISP Embedded
• 99% Capture Rate & 98% Plate Recognition Rate
• A.I. (Artificial Intelligence) Powered LPR & Video Analytic Algorithms at Edge
• High Speed ANPR up to Approx. 155mph - 2~3 Lane Coverage
• Numerous Vehicle Attributes (Metadata): Color, Brand, Type, Direction, No-Plate, Plate Color
• Traffic Violation Detection
• Traffic Flow Statistics
• Large Edge White/Black List
• High-Capacity Edge Storage up to 1TB
• ONVIF, CGI/API/SDK/MQTT and more for 3rd Party Systems
• 4G LTE Network for Wireless Transmission (Optional)
• Built-in GPS for Precise Location
• Multi-Web Browser Support - Plug-in Free
• Alarm/Relay External I/O device support (opto-isolated inputs)
• RS-485 Control Support
• External Strobe Output Support
• White Housing
• Weatherproof up to IP67 rating
• Wide Operating Temp. Range: -40°C ~ 70°C
• Surge Protection
• 24VDC Power Support
• NDAA Compliant

Milesight TS5510-GH Specifications:

Cameras (DUAL)
Image Sensor Color, 2/3" Global Shutter
Min. Illumination Color: 0.001 Lux@ (F1.4, AGC ON)
Shutter Time 30 us- 40000 us
Day/Night Mode Day/Night/Auto
Supplement Light IR: IR Strobe Light (16 light beads)
IR Distance: 60m
IR Wave Length: 850nm (Default), 740nm (Optional)
Road Traffic Management
Max. ANPR Range Up to 50m (or 164ft)
Max. Vehicle Speed 250 km/h or 155mph
Coverage Recommended for 2~3 lanes
Capture Rate Up to 99%
Recognition Accuracy Up to 98%
Country Region Supported More than 74 countries and regions
Attributes Identification Plate Color, Vehicle Type, Vehicle Color, Vehicle Brand, No-plate Vehicle Capture
Violation Management Reverse Driving, Vehicle Attributes Event Detection
White/Black List Up to 2000 records inside the camera
LPR Smart Search Support

Interface
Ethernet 1*RJ45 10M/100M/1000M Ethernet Port
RS485 Support
Input 4 * Opto-isolated Input
Output 2 * Strobe Output
1 * Relay Output

Lens
Lens 15-50mm, Motorized zoom and focus
Mount Custom mount
Field of View horizontal FOV 41.4° to 10.3°, vertical FOV 26.8° to 8.42°, diagonal FOV 32° to 13.3°

Video
Max. Resolution 2464x2056 (5-Megapixel)
Max. FPS 30fps @ 5-Megapixel
Video Compression H.265/H.264/MJPEG
Video Bit Rate 16Kbps~16Mbps (CBR/VBR Adjustable)
Image Setting Brightness/Contrast/Saturation
Privacy Masking Up to 24 Areas (per Sensor)

Wireless Network
(Optional)
Cellular 4G LTE
NA: B2/B4/B5/B12/B13/B25/B26
EU: B1/B3/B7/B8/B20/B28
AU: B1/B2/B3/B4/B5/B7/B8/B28/B66
SIM Card Nano SIM

System
System Compatibility API, HTTP, TCP, MQTT, ONVIF Profile G & S & T
Storage Support microSD/SDHC/SDXC Card Local Storage, up to 1TB

General
GPS Built-in High-accuracy GPS Module
Working Temperature -40°C ~ 70°C
Working Humidity 0~95% (Non-condensing)
Power Consumption 22W MAX or 26W MAX (With IR on)
Weather Proof Up to IP67-rated for Weather-resistant Performance
Power Supply 24 V DC/AC
Weight 4.3Kg
Dimensions 121mmx295mmx245mm
(Without Mounting Bracket)
Warranty 3 Years
