Milesight TS8266-X4VPE 4K Road Traffic AI RADAR LPR 4x IR Bullet IP Security Camera

Milesight TS8266-X4VPE 4K Road Traffic AI RADAR LPR 4x IR Bullet IP Security Camera is a specialized camera built to empower a new age in smart vehicle traffic monitoring, management and surveillance. Coupling core factors like 4K Ultra HD, Telephoto motorized Zoom lens plus long-range IR Night Vision with A.I. enhanced ALPR (aka LPR) and other road traffic video analysis as well as an integrated 3D Radar, this Milesight Road Traffic LPR AI IP Camera sets new standards in market. Its well-developed design incorporates a wide range of fundamental capabilities spanning from its intuitive web interface to its large capacity edge-storage or its external device I/O connectivity. The unit’s wide array of benefits is realized as it satisfies countless potential combinations of demands in a single, pre-built product within a compact easy to deploy build. The device has all the perks from cutting-edge media compression methods to in-depth image settings, alarm triggers or vast IT protocol conformance assuring industry wide integration potential. Likewise, these units are built tough, boasting high weatherproof standards as well as advantages like high impact vandal resistance that match perfectly with flexible mounting and flexible power input for truly easy adaptation to various installation needs.

The Milesight TS8266-X4VPE 4K Road Traffic AI RADAR LPR 4x IR Bullet IP Cameras were made to propel vehicle traffic monitoring, management and surveillance to the next level. Milesight's A.I. powered ALPR (Automatic License Plate Recognition) or aka ANPR (Automatic Numeric Plate Recognition) and other traffic focused Video Analytic package operates within this camera at the edge, enabling diverse and efficient system designs of all kinds. From Traffic Violation Detections to granular vehicle attribute data capture like color, make and type the device can accommodate many project requirements of varying purposes or act for multi-purpose objectives. With an added 3D Radar, this configuration demonstrates how Milesight's Road Traffic IP Cameras are pioneering the way for the next age in smart traffic management. In fact, this innovative 3D Radar component boost Milesight's powerful LPR Camera series to the peak of current technologies enabling all sorts of gains including additional metadata like speed measurements to greater multi-lane coverage for a variety of its Traffic Flow statistics. From stand-alone abilities to deep operational functions when used with Milesight NVRs, CMS or VMS software products the Milesight 4K Traffic AI RADAR LPR IP Security Cameras are equally built to support 3rd party system integration with modern formats of ONVIF to API/SDK access options for custom developed system solutions!

Milesight TS8266-X4VPE Main Features:

• 1/1.8" 8 MegaPixel (3840x2160) 4K @ 30fps Real-time
• Zoom lens: 8-32mm, 4X Optical Zoom: HFOV 44° ~ HFOV 13°/ VFOV 25° ~ VFOV 7°
• High Power IR Night Vision up to 180m
• ANPR Day Range up to 130m - ANPR Night Range w/Illumination: up to 60m
• Color: 0.009 Lux @F1.6, B/W: 0 Lux with IR on
• Super Wide Dynamic Range (WDR 120dB)
• A.I. (Artificial Intelligence) Powered LPR Algorithm
• Long Range ANPR Function w/95% Accuracy
• High Speed ANPR up to Approx. 75mph - 2 Lane Coverage
• Numerous Vehicle Attributes: Color, Brand, Type, Direction, No-Plate, Plate Color
• 3D RADAR Enables 4 Lane Dataset Analysis for extra Precise Distance, Direction, Speed Detections
• 3D RADAR Enables Enhanced Detections with high resistance to weather, obstructions & is light immune
• Traffic Violation Detection
• Traffic Flow Statistics - ENHANCED BY 3D RADAR
• Evidence Camera Linkage
• High-Capacity Edge White/Black List
• 3-Axis Camera Orientation
• ONVIF, CGI/API/SDK and more for 3rd Party Systems
• Multi-Web Browser Support - Plug-in Free
• High-Capacity Micro SD Card Support
• Audio External I/O device support (i.e. mics/speakers)
• Alarm/Relay External I/O device support
• White Housing
• Weatherproof up to IP67 rating
• Vandalproof High Impact IK10
• Optional Heating Module (for -60°C)
• A62 Junction Box Included
• Surge Protection
• PoE OR 12VDC Power Support

Milesight TS8266-X4VE Specifications:

Camera
Name NDAA AI Road Traffic Radar Pro Bullet Plus Camera
Image Sensor 1/1.8″ Progressive Scan CMOS
Min. Illumination Color: 0.009Lux@F1.6
B/W: 0Lux with IR on
WDR 120dB Super WDR
Shutter Time 1/100000s~1s
Day/Night Mode Day/Night/Auto/Customize/Schedule
IR Wave Length 850nm (Default); 740nm (Optional)
Illumination Distance Up to 180m
S/N >55dB

Lens
Lens 8~32mm, 4X Optical Zoom
Field of View H44°~H13°/D51°~D15°/V25°~V7°
Mount Φ14
Focus Control Auto/Manual
Aperture F1.6~F1.7
Iris Control Auto

Road Traffic Management
Max. Vehicle Speed 120km/h
Recognition Accuracy >95%
Coverage 2 lanes
Country/Region Supported More than 80 countries and regions
ANPR Distance Up to 130m during the day; Up to 60m during the night with illumination
Attributes Identification Plate Color, Vehicle Type, Vehicle Color, Vehicle Brand, No-plate Vehicle Capture, Vehicle Direction Detection, Speed Detection, Traffic Flow Detection
Smart Traffic Function Evidence Camera Linkage, Specific Lane Management
White/Black List Up to 20,000 records inside the camera
LPR Smart Search Support

Radar
Working Frequency 60GHz, 61~62GHz
Capture Rate >99% (Traffic jam >95%)
Lane Coverage 1~4 Lanes (Recognition ≥95% individually）
Tracking Target Up to 32
Speed Detection Range ±5km/h~±120km/h
Speed Detection Accuracy ±0.36km/h
Detection Distance Up to 90m
Distance Detection Accuracy ±0.4m
Angle Measurement Accuracy ±0.5°
Installation Height 2~7m

Interface
Ethernet 1*RJ45 10M/100M Ethernet Port
Audio I/O 1/1
Alarm I/O 1/1

Video
Max. Image Resolution 3840x2160
Primary Stream 60Hz: 30fps@ (3840x2160, 3072x2048, 2592x1944, 2592x1520, 2048x1536, 1920x1080, 1280x960, 1280x720, 704x576)
50Hz: 25fps@ (3840x2160, 3072x2048, 2592x1944, 2592x1520, 2048x1536, 1920x1080, 1280x960, 1280x720, 704x576)
Secondary Stream 60Hz: 60fps@ (704x576, 640x480, 640x360, 352x288, 320x240)
50Hz: 50fps@ (704x576, 640x480, 640x360, 352x288, 320x240)
Tertiary Stream 60Hz: 30fps@ (1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240)
50Hz: 25fps@ (1920x1080, 1280x720, 704x576, 640x480, 640x360, 320x240)
Video Compression H.265+/H.265(HEVC)/H.264+/H.264/MJPEG
Video Bit Rate 16Kbps∼16Mbps (CBR/VBR adjustable)
Privacy Masking Up to 8 Areas (Mask Area and Mosaic Area are optional)
ROI Up to 8 areas
Image Settings Saturation/Brightness/Contrast/Sharpness

Network
Network Storage NAS (Support NFS, SMB/CIFS), ANR
Network Protocols IPv4/IPv6, ARP, TCP, UDP, RTCP, RTP, RTSP, RTMP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, SNMP, UPnP, Bonjour, SIP, PPPoE, VLAN, 802.1x, QoS, IGMP, ICMP, SSL, TLS 1.2

Audio
Audio Compression G.711/AAC/G.722/G.726
Audio Sampling Rate 8/16/32/44.1/48KHz
Audio Bit Rate 16~256kbps
Two-way Audio Support

System
System Compatibility API, HTTP, TCP, ONVIF Profile G & M & S & T
Storage Support microSD/SDHC/SDXC Card Local Storage, up to 1TB
Advanced Function BLC, HLC, 2D DNR, 3D DNR, Defog, AWB, IP Address Filtering, AGC, Anti-flicker, Corridor Mode, Deblur, Watermark
SIP/VoIP Support Yes, Voice & Video-over-IP
Event Trigger Black/White List, Attributes Event, Motion Detection, Network Disconnection, External Input, Audio Alarm, etc.
Event Action FTP Upload, SMTP Upload, SD Card Record, External Output, SIP Phone, HTTP Notification, etc.

General
Working Temperature -40°~60°C
Working Humidity 5~95%(Non-condensing)
Power Supply PoE (802.3at) / DC 12V±10%
Power Consumption 9W MAX, 15W MAX (With IR on)
Housing Up to IP67-rated for weather-resistant performance
Surge Protection 4KV
Weight 1623g
Dimensions 320mmX134mmX171mm
Warranty 3/5 Years
