Tiandy TC-C35MP Spec I5/A/E/Y/M/H/2.7-13.5mm/V4.0 5MP AI EW Super Starlight IR Vandal Dome IP Security Camera

Tiandy TC-C35MP Spec I5/A/E/Y/M/H/2.7-13.5mm/V4.0 5MP AI EW Super Starlight IR Vandal Dome IP Security Cameras grant top tier performance with rich functionality and affordable cost. Supporting wide screen format 5-megapixel video, the device boasts other significant advantages such as superior color video to extreme low light conditions for greater evidence capture as well as visual satisfaction. The device includes all the pro perks like a built-in Motorized Lens to above average IR Night Vision ensuring absolute video protection of large areas even in scenes with zero ambient lighting. The benefits don't stop there, from a built-in microphone to cutting edge video and audio compression methods, this Tiandy Pro series IR Vandal Dome IP Camera provides capabilities not only advantageous to security or surveillance but also for all sorts of pro-video system requirements. As example, modern formats of ONVIF to numerous IT protocols like RTSP or RTMP promise wide industry integration for all types of 3rd party systems.

Tiandy TC-C35MP Spec I5-A-E-Y-M-H-2.7-13.5mm-V4.0 5 Megapixel AI Super Starlight IR Vandal Dome IP Camera includes even more with in-depth functionality across all aspects. Consider the units large suite of on-board Video Analytics including A.I. enhanced vehicle/human classification to Tiandy's Early Warning (EW) function which can intelligently and automatically trigger alarm responses such as triggering external speakers, sirens or lighting enabling the device to provide active deterrence even all on its own. Alternative factors like how the device is built with Rugged standards featuring an IK10 high impact, vandal resistant and weatherproof IP67 rating ensure reliable operation even in the most demanding outdoor environments. Further large capacity edge storage, Alarm / Audio I/O connectivity, flexible 12V DC or PoE Power Input to plug-in free web browser interface, this Vandal Dome offers a top of the market product at a great price.

Tiandy TC-C35MP Spec I5AEYMH2.713.5mmV4.0 Main Features:

• Motorized Lens 2.7-13.5mm
• Up to 3072×1728@30fps, 1920x1080@60fps
• S+265/H.265/H.264/M-JPEG
• Min. illumination Color: 0.0008Lux@F1.2
• Smart IR, IR Range: 50m
• Built in Mic & Speaker
• Support Video Analytics
• Support A.I. Human/Vehicle Classification
• Support Early Warning
• Support Face Capture Mode
• Built-in Mic, audio I/O 1/1, alarm I/O 2/1
• Plugin Free Web Browser Interface
• Operating Conditions -35°~65°C, 0~95% RH
• IP67 Weatherproof, IK10 High Impact Vandal-Proof
• POE or 12VDC
• NDAA

Tiandy TC-C35MP Spec I5AEYMH2.713.5mmV4.0 Specifications:

Camera
Image Sensor 1/1.8" CMOS
Signal System PAL/NTSC
Min. Illumination Color: 0.0008Lux@ (F1.2, ACG ON), B/W: 0Lux with IR
Shutter Time 1s to 1/100,000s
Day & Night Dual IR Cut Filter with Auto Switch
Wide Dynamic Range 120dB
Angle Adjustment pan 0~330°, tilt 0~75°, rotate 0~350°

Lens
Lens Type Motorized
Focus 2.7-13.5mm
Lens Mount 14
Aperture F1.2~F2.2, DC
FOV Horizontal field of view: 106.9°~48.7°

Illuminator
IR LEDs 14
IR Range Up to 50m
Wavelength 850nm

Compression Standard
Video Compression S+265/H.265/H.264/M-JPEG
Video Bit Rate 32Kbps~16Mbps
Audio Compression G.711A/G.711U/ADPCM/AAC
Audio Bit Rate 8K~48Kbps

Max. Resolution 3072×1728
Main Stream
PAL: 25fps (3072×1728, 2560×1440, 2304×1296), 50fps (1920×1080, 1280×720)
NTSC: 30fps (3072×1728, 2560×1440, 2304×1296), 60fps (1920×1080, 1280×720）
Sub Stream
PAL: 25fps (704×576, 704×288, 640×480, 352×288)
NTSC: 30fps (704×480, 704×240, 640×480, 352×240)
Third Stream
PAL: 25fps (1920×1080, 1280×720, 704×576, 704×288, 352×288)
NTSC: 30fps (1920×1080, 1280×720, 704×480, 704×240, 352×240)
Image Setting Saturation, brightness, contrast, sharpness, adjustable by client software or web browser
Image Enhancement BLC/3D DNR/HLC/Corridor Format
ROI: Support 8 fixed regions of coding
OSD: 1616, 2424, 3232, 4848, 64x64, 96x96, adaptable size, Letters Such as Week, Date, Time, Total 5
Regions
Picture Overlay Yes
Privacy Mask Yes, 4 regions
Smart Defog Yes

Feature
Alarm Trigger: Event Input, Event Output, Motion Detection, Mask Alarm, Disk Full, Disk R/W Error, IP Address Conflict, MAC Address Conflict, FTP Server Exception
Video Analytics:
Tripwire, Double Tripwire, Perimeter, Object Abandon, Object Lost, Loitering, Running, Parking,
Crowed, People Counting, On Duty Detection, Video Abnormal, Audio Abnormal, Heatmap,
Face Capture: (Face Detection), Safety Helmet Detection, Human/Vehicle Classification
Early Warning (EW) Yes

Network
ANR: Yes, auto store video in SD card when NVR disconnected, and upload video to NVR when resumed
connection (Only Support Tiandy ANR NVR)
Protocols: TCP/IP, ICMP, HTTP, HTTPS, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, MULTICAST, UPnP, FTP,
IPV4, NTP, SMTP, IGMP, 802.1x, QoS, IPV6, ARP, UDP, SNMP, SSL, SIP, Telnet, SNTP, RTMP, SFTP,
NFS
System Compatibility: ONVIF (PROFILE S/T/G/M), SDK, Milestone, CGI, P2P
Remote Connection 7
Client Easy7, EasyLive
Web Version Web6

Interface
Communication Interface 1 RJ45 10M/ 100M self-adaptive Ethernet port, RS 485
Audio 1/1, Mic in
Alarm 2/1
Reset Button Yes
On-board storage Built-in Micro SD card slot, up to 512 GB

General
Web Client Language - (17 languages): English, Russian, Spanish, Korean, Italian, Turkish, Simple Chinese, Traditional Chinese, Thai, French, Polish, Dutch, Hebraism, Arabic, Vietnamese, Ukrainian, German
Operating Conditions: -35～65°C, 0～95% RH
Power Supply: DC12V±25% / PoE 802.3af
Power Consumption MAX: 7.5W (12V) MAX: 9W (PoE)
Protection IP67, IK10, Lightning protection, surge protection and voltage transient protection meets EN 55035:2017
Dimensions: Φ143×124mm (Φ5.63×4.88inch
Weight 0.85Kg (1.87lb)
